Electrical System Studies
Using ETAP, SKM and XGSLab software for,
- Arc Flash Study (IEEE 1584)
- Cable Ampacity Calculation (IEC 60364, BS 7671 and IEC 60502)
- Ground Grid Design (IEEE 80)
- Harmonic Load Flow (IEE 519)
- Load Flow Analysis
- Motor Starting Analysis
- Optimal Capacitor Placement Analysis
- Optimal Power Flow Analysis
- Protective Device Coordination
- Reliability Assessment Analysis
- Short Circuit Study (IEC 909)
- Unbalanced Load Flow Analysis
- Underground Thermal Analysis
Testing & Maintenance
We provide testing and maintenance for switchgear, transformer and cables.
For switchgear
- Secondary injection test for protection relays
- Primary injection test for CT
- Contact resistance measurement
- Applied voltage withstand test
- Partial discharge measurement
For transformer
- Turns ratio and vector group measurement
- Winding resistance measurement
- Dissipation factor measurement
- Sweep frequency response analysis
- Dielectric frequency response analysis
- Applied voltage withstand test
- Induced voltage withstand test
- On site DGA of transformer oil
- Partial discharge measurement
For cable
- Voltage withstand test using AC VLF and AC 50 hertz source
- Monitored voltage withstand using AC VLF and AC 50 hertz test source
- Dissipation factor measurement
- Partial discharge measurement
Consultancy
- Application for electricity connection to the local grid company, SPPG.
- Consultancy and project management.
- Engineering, procurement and construction for upgrading of switchgear , transformer and cable.
- Independent review of the electrical design , done by others for compliance with local code of practice.
- Audit of the electrical system of existing installations.
- Root cause analysis for electrical faults.
Licensing
We provide licensing service for the regulatory compliance to the Electricity Act and its associated Electricity Regulations.
These range from small installations of 400 volts to large installations of 230,000 volts.
Our reference list includes:
- ExxonMobil, Micron at 230,000 volts.
- AUO, ExxonMobil, Keppel Seghers, Singtel DCW, SingSpring desalination, TPC, UMC at 66,000 volts.
- Applied Material, Ascendas, Chevron, Capitaland, Sumitomo Chemical, Singapore Refining Company, Sembcorp, etc at 22,000 volts.
Training
ON Engineers provides a licensed electrical worker (LEW) preparatory course.
It is to share experience and knowledge to enable the attendees to be better prepared in attaining the LEW qualification from EMA (Energy Market Authority) of Singapore.
The course is made up of 8 modules.
- Module 1 – Introduction
- Module 2 – Overview of electrical licensing
- Module 3 – Electrical hazards and safety practice
- Module 4 – Overview of SS 638, Code of practice for electrical installation
- Module 5 – Other mandatory code of practice for generators and temporary supply
- Module 6 – Electrical testing and inspection
- Module 7 – Design requirements for 400 volts switchboard
- Module 8 – Question and answer
Trainers | : | ON Engineers’ LEWs and staff |
Date | : | – |
Location | : | |
Time | : | |
Fees | : | (Subject of GST) |
Meals Provided | : | Lunch and 2 tea breaks |
(The course will include lunch and light refreshments during the breaks)
Click HERE to enroll.
If you are a member of the Singapore Electrical Contractors and Licensed Electrical Workers Association (“SECA”) and are interested to attend, please click HERE.
For enquiries, kindly contact us at : +65 6795 4666 or : training@onengineers.com.
